Voltage (VAC):

Hertz:

Phase:

RPM:

Motor Type:

Insulation:

Duty Rating:

Shaft Seal:

Motor Shaft:

Upper Motor Bearing:

Lower Motor Bearing:

Cooling:

Discharge Size (NPT):

Cord Length (ft.):

Cord Type:

Motor Housing:

Volute:

Impeller Material:

Switch:

Pump On/Off Levels:

O-Rings:

Solids Handling:

Max. Liquid Temperature:

Fasteners:

120

60Hz

Single

3,450

PSC

Class B

S1, Continuous

Mechanical Seal

Stainless Steel

Ball Bearing

Ball Bearing

Oil Cooled

1-1/2" NPT

10 ft.

SJTW 18AWG

Cast Iron

Thermoplastic

Thermoplastic

Snap-Action Vertical

9.6" / 4.9"

NBR

1/2"

130 degrees (F)

Stainless Steel

Product Brochure

Dimensional Drawing

Installation Guide

Product Catalog

• Passes a 1/2" solid
• Cast iron body with thermoplastic intake
• High efficient, PSC motor with thermal overload protection
• Rated for continuous duty
• Upper and lower ball bearings
• Carbon ceramic mechanical seal
• Includes removable PumpPegs^TM to lift pump above debris on the basin floor
• Snap-action vertical switch
• 10 ft. power cord
